PRODUCT SPECIFICATION
Class
17"
Ink Type
12 Inks: MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Maximum Print Resolution
Maximum Print Resolution¹
2,400 x 1,200 dpi
Printing Speed
Printing Speed¹
A2 (LU-101 colour): Approx. 3min 35s
A2 (PT-101 colour or mono): Approx. 6mins
Dimensions, Weight
Approx. 723 x 435 x 285 mm
Weight approx. 32.3kg (including print head and inks)
Power Supply
AC 100-240V（50-60Hz)
Power consumption (approx 34W)¹
Standby consumption (approx 1.1W)
Power off (approx 0.3W)
Operational Environment
Temperature: 5-35°C, Humidity: 10-90%RH (no dew condensation)¹
Acoustic Noise
approx. 41.0 dB(A) - Photo (4"x6")¹
approx. 40.8 Db(A) - Document (A4. B/W), Quiet Mode OFF²
approx. 40.4 Db(A) - Document (A4. B/W), Quiet Mode ON
Operation Panel Display
3.0" (320 x 240 TFT LCD), Key x 13, LED x 2
21 Languages Selectable: English/German/French/Turkish/Italian/Spanish/Portuguese/Dutch/Polish/Hungarian/Danish/Norwegian/Swedish/Finnish/Czech/Russian/Simplified Chinese/Traditional Chinese/Thai/Indonesian/Japanese
Memory
1GB
INTERFACE TYPE & SOFTWARE
Supported Operating Systems
Supported Operating Systems¹
Windows 32bit:
Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008
Windows 64bit:
Windows Vista , Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008/2008R2, Windows Server 2012/2012R2
*Windows RT(Windows 8 ARM version) is not supported
Macintosh
OS10.7.5 - OS10.10.x
Supported Mobile Systems
iOS
Android
Interface
Hi Speed USB Type: Built-in
USB 2.0 High-Speed Full Speed (12 Mbit/sec), High Speed (480 Mbit/sec), Bulk transfer
Wireless LAN
Wi-Fi
IEEE802.11n
IEEE802.11g
IEEE802.11b
Please refer to the user manual for instructions on how to activate/deactivate the wireless LAN.
Ethernet
Type Built-in:
IEEE 802.3 10base-T
IEEE 802.3u 100base-TX
Auto-Negotiation
Smart device & Cloud apps
Canon PRINT app (iOS or Android)
Pro Gallery Print app (iPad only)
PIXMA Cloud Link
Apple AirPrint
Camera direct
Wi-Fi Pictbridge
Software
Print Studio Pro, Quick Utility Toolbox
PRINT HEAD
Type
Canon Bubble-jet on Demand
Head Configuration
12 colors integrated type (4 colors chips x 3)
Nozzle Pitch
600dpi x 2
Nozzle per Chip
1,536 nozzles x 12 colors, includes Non-firing nozzle detection and compensation system
Droplet Size
Minimum 4pl
INK TANK
Model
LUCIA PRO Ink Tanks:
PFI-1000
MBK/ PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO
Page yield (4x6" PT-101)
Page yield (4x6" PT-101)¹
Number of 10x15cm photos
Matte Black (MBK): 5490 photos*
Photo Black (PBK): 2205 photos*
Grey (GY): 1465 photos*
Photo Grey (PGY): 3165 photos*
Photo Cyan (PC): 5140 photos*
Cyan (C): 5025 photos*
Photo Magenta (PM): 3755 photos
Magenta (M): 5885 photos*
Yellow (Y): 3365 photos
Red (R): 5355 photos*
Blue (B): 4875 photos*
Chroma Optimizer (CO): 680 photos
* Estimated Supplemental Yield
Page yield (A2 PT-101)
Page yield (A2 PT-101)¹
Number of A2 colour photos
Matte Black (MBK): 1600 photos*
Photo Black (PBK): 256 photos*
Grey (GY): 106 photos*
Photo Grey (PGY): 270 photos*
Photo Cyan (PC): 600 photos*
Cyan (C): 675 photos*
Photo Magenta (PM): 374 photos*
Magenta (M): 965 photos*
Yellow (Y): 329 photos
Red (R): 935 photos*
Blue (B): 545 photos*
Chroma Optimizer (CO): 97 photos*
* Estimated Supplemental Yield
MEDIA HANDLING
Media Feeding
Rear tray/Manual feed slot
Media Type
Plain Paper,
Photo Paper Plus Glossy II,
Photo Paper Pro Platinum,
Photo Paper Pro Luster,
Photo Paper Plus Semi-gloss,
Photo Paper Pro Premium Matte,
Matte Photo Paper,
Other Fine Art, Canvas and Glossy Photo Papers
Media size
A5, A4, A3, A3+, A2, B5, B4, B3,
4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR, LGL, LDR
Media Thickness
Rear tray: Plain paper 64-105g/m2, Canon specialty paper Max. 300g/m2,
Rear tray thickness: 0.1-0.3mm
Manual feed slot: Canon specialty paper Max. 400g/m2,
Manual feed thickness: 0.1-0.7mm
Media Width
Rear tray: 89-432mm,
Manual feed slot: 203.2-432mm
Minimal Printable Paper Length
Rear tray: 127mm
Manual feed slot: 254mm
Maximum Printable Paper Length
1200mm
Margins (Top, Bottoms, Sides)
Recommended - Top margin: 57mm, Bottom margin: 55mm, Left/Right: 3.4mm
(LTR/LGL: Left margin 6.4mm, Right margin 6.3mm）
Printable area -Top margin 3mm, Bottom margin 5mm, Left/Right margin 3.4mm
(LTR/LGL: Left margin 6.4mm, Right margin 6.3mm）
Media Width for Borderless Printing
Media Width for Borderless Printing¹
A4, A3, A3+, A2, 4x6", 5x7", 8x10", 10x12", 14x17", 17x22", LTR
CONSUMABLES
Ink Tank
PFI-1000 MBK/PBK/C/M/Y/PC/PM/GY/PGY/R/B/CO (80ml)
Maintenance Cartridge
MC-20
Disclaimer
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Footnote
¹ Ink droplets can be placed with a pitch of 1/2400 inch at minimum.
¹ Print speed is based on the default setting using ISO/JIS-SCID N5 and does not take into account data processing time on host computer. Print speed may vary depending on system configuration, interface, software, document complexity, print mode, page coverage, type of paper used etc.
¹ When printing ISO/JIS-SCID N2 pattern on A4 size Photo Paper Pro Platinum (PT-101) using default settings.
¹ The performance of the printer may be reduced under certain temperature and humidity conditions.
¹ When printing ISO/JIS-SCID N2 pattern on Photo Paper Pro Platinum using default settings.
² Acoustic Noise is measured based on ISO7779 standard.
¹ Minimum system reguirements is according to that of OS and application software used
¹ Declared yield value in accordance with ISO/IEC 29103. Values obtained by continuous printing.
¹ Declared yield value in accordance with ISO/IEC 29103. Values obtained by continuous printing.
¹ Paper types NOT supported for borderless printing are as follows: Photo Stickers
