35MM FILM EQUIVALENT FOCAL LENGTH
Angle of view (horzntl, vertl, diagnl)
65° - 6° 50’, 46° - 4° 35’, 75° - 8° 15’
Lens construction (elements/groups)
23 / 16
No. of diaphragm blades
8 (circular type)
Minimum aperture
f/22-38 (f/22-40 for cameras featuring 1/3-stop increments)
Closest focusing distance (m)
0.7m to infinity (at all zoom focal lengths)
Maximum magnification (x)
0.06 (Wide); 0.3 (Tele)
IMAGE STABILIZER
AF actuator
Ring USM
Filter diameter (mm)
77
Max. diameter x length (mm)
92 x 184
Weight (g)
1,670
Magnification - Extension Tube EF12 II
Compatible
Magnification - Extension Tube EF25 II
Only compatible in Tele mode
Lens Cap
E-77U / E-77II
Lens hood
ET-83G
HARD CASE
Soft case
LZ1324
G.F.HOLDER IV (HOOD IV*)
Extenders EF1.4x II and EF2x II
Not compatible
